High Power Ceramic Wirewound Resistors , 40W 80W Inverter Braking Resistor

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Rated Power | 40W, 80W | Resistance Range | 0.1R-1K |
---|---|---|---|
TCR | ≤250PPM | ||
High Light | High Power Ceramic Wirewound Resistors,40W Inverter Braking Resistor,80W Inverter Braking Resistor |
Product Description
High Power Ceramic Wirewound Resistor for inverter braking
Features:
- High load power
- Low TCR and noise
- Good heat dissipation and high insluation
Dimensions:
Type | Rated power (w) | Resistance range(Ω) | Tolerance ±(%) | Max Wording Voltage(V) | Max Overload Voltage(V) |
外形尺寸 Dimension (mm) |
||||
L±1.5 | W±1.0 | H±1.0 | H±3.0 | W1±0.2 | ||||||
BKG | 40 | 0.1~1K | 1(F) 2(G) 5(J) 10(K) |
150 | 500 | 59 | 26 | 14 | 24 | 0.65 |
BKG | 80 | 0.1~1K | 150 | 500 | 90 | 45 | 15 | 24 | 0.65 |
Electrical Performance:
Inspection item | Requirement | Test method |
Solder ability | Soldering Area ≥90% | 260±5℃ ,2±0.5 seconds |
Withstand voltage | No breakdown, arc flying phenomenon | 500VAC,5s |
Temperature coefficient | ≤±250×10-6/℃ | Evironment temperau+100℃ |
Resistance to sold,heat | △R≤±(1%R+0.05Ω) | 350±5℃ ,3.5±0.5 seconds |
Over load | No visible damage, △R≤±(1%R+0.05Ω) | 10 times,5s |
Terminal tensile strength | No visible damage, △R≤±(1%R+0.05Ω) | 10N,10s |
Temperature Change | No visible damage, △R≤±(2%R+0.05Ω) | -55℃~+200℃,3 Cycles |
Vibration | No visible damage, △R≤±(2%R+0.05Ω) | 10Hz~500Hz,50m/s²,30min |
Damp heat steady state | No visible damage, △R≤±(5%R+0.1Ω) | 40±2℃,RH(90~95)%,96h |
Endurance | No visible damage, △R≤±(10%R+0.1Ω) | 25℃,Ur,1000h |
